Forum Discussion

RR-IT-GUY's avatar
RR-IT-GUY
Rising star
5 days ago

Intermittent Network - Drop outs

Intermittent Network - Drop outs

32 Replies

  • 3.0 Downstream channels

    Channel    Frequency (Hz)    Power (dBmV)    SNR (dB)    Modulation    Channel ID
    1    347000000    1.3    38    QAM 256    27
    2    139000000    0.6    35    QAM 256    1
    3    155000000    0.5    35    QAM 256    3
    4    163000000    0.4    35    QAM 256    4
    5    171000000    0    35    QAM 256    5
    6    179000000    0.2    36    QAM 256    6
    7    187000000    0.4    35    QAM 256    7
    8    195000000    0.5    35    QAM 256    8
    9    203000000    -1    35    QAM 256    9
    10    211000000    -1    35    QAM 256    10
    11    219000000    -1.4    36    QAM 256    11
    12    227000000    -1.5    36    QAM 256    12
    13    235000000    -1.2    36    QAM 256    13
    14    243000000    0.7    36    QAM 256    14
    15    251000000    0.6    36    QAM 256    15
    16    259000000    0.4    36    QAM 256    16
    17    267000000    0.4    36    QAM 256    17
    18    275000000    0.3    36    QAM 256    18
    19    283000000    0    36    QAM 256    19
    20    291000000    0.3    37    QAM 256    20
    21    299000000    0.7    37    QAM 256    21
    22    307000000    0.9    37    QAM 256    22
    23    315000000    0.9    37    QAM 256    23
    24    323000000    1    37    QAM 256    24
    25    331000000    1    37    QAM 256    25
    26    339000000    1.1    37    QAM 256    26
    27    355000000    1.5    38    QAM 256    28
    28    363000000    1.7    38    QAM 256    29
    29    371000000    1.7    38    QAM 256    30
    30    379000000    1.8    38    QAM 256    31
    31    387000000    1.8    38    QAM 256    32
    3.0 Downstream channels

    Channel    Locked Status    RxMER (dB)    Pre RS Errors    Post RS Errors
    1    Locked    38    0    0
    2    Locked    35    1    0
    3    Locked    35    4    0
    4    Locked    35    0    0
    5    Locked    35    0    0
    6    Locked    36    0    0
    7    Locked    35    0    0
    8    Locked    35    0    0
    9    Locked    35    0    0
    10    Locked    35    0    0
    11    Locked    36    0    0
    12    Locked    36    0    0
    13    Locked    36    0    0
    14    Locked    36    0    0
    15    Locked    36    0    0
    16    Locked    36    0    0
    17    Locked    36    0    0
    18    Locked    36    0    0
    19    Locked    36    0    0
    20    Locked    37    0    0
    21    Locked    37    0    0
    22    Locked    37    0    0
    23    Locked    37    0    0
    24    Locked    37    0    0
    25    Locked    37    0    0
    26    Locked    37    0    0
    27    Locked    38    0    0
    28    Locked    38    0    0
    29    Locked    38    0    0
    30    Locked    38    0    0
    31    Locked    38    0    0
    3.1 Downstream channels

    Channel    Channel Width (MHz)    FFT Type    Number of Active Subcarriers    Modulation (Active Profile)    First Active Subcarrier (Hz)
    33    94    4K    1840    QAM 4096    1108
    3.1 Downstream channels

    Channel ID    Locked Status    RxMER Data (dB)    PLC Power (dBmV)    Corrected errors (Active Profile)    Uncorrectable errors (Active Profile)
    33    Locked    0    -2.8    7994036    0

  • 3.0 Upstream channels

    Channel    Frequency (Hz)    Power (dBmV)    Symbol Rate (ksps)    Modulation    Channel ID
    0    49600000    48.5    5120    QAM 64    1
    1    43100000    48.8    5120    QAM 64    2
    2    36600000    48.5    5120    QAM 64    3
    3    30100000    49    5120    QAM 64    4
    4    23600000    49.5    5120    QAM 64    5
    3.0 Upstream channels

    Channel    Channel Type    T1 Timeouts    T2 Timeouts    T3 Timeouts    T4 Timeouts
    0    ATDMA    0    0    0    0
    1    ATDMA    0    0    0    0
    2    ATDMA    0    0    0    0
    3    ATDMA    0    0    0    0
    4    ATDMA    0    0    1    0
    3.1 Upstream channels

    Channel    Channel Width (MHz)    Power (dBmV)    FFT Type    Modulation
    6    10.4    43.7    2K    QAM 256
    3.1 Upstream channels

    Channel    Channel Type    Number of Active Subcarriers    First Active Subcarrier (Hz)    T3 Timeouts    T4 Timeouts
    6    OFDMA    208    74000000    0    0

  • legacy1's avatar
    legacy1
    Alessandro Volta

    "Maximum Number of CPEs    3"

    How did you get 3? this normally is 1

    • RR-IT-GUY's avatar
      RR-IT-GUY
      Rising star

      I didn't even spot that, would that include the TV box?

      If not, seems someone at Virgin has been messing around with the profiles.



      I know the router has been replaced twice before so maybe they forgot to remove the bindings on the CMTS.



      I wonder what happens if you plug 3 modems in? Never heard of that being done before.



      Has anyone ever heard of more than 1 CPE?

      • Nednats's avatar
        Nednats
        Just browsing

        Yes the Tivo boxes count as CPEs

    • RR-IT-GUY's avatar
      RR-IT-GUY
      Rising star

      It is a 5, applogies it didn't reply to you directly, I haven't used the new forum until now

    • loopback7084's avatar
      loopback7084
      On our wavelength

      Had a very similar thing this week. Just "magically" started one afternoon... and just as mysteriously went away again... ( 2025-07-18 )

      ( Yesterday evening - 2025-07-21 )

      it's been rock solid before. No explanation at all from VM.

  • Adduxi's avatar
    Adduxi
    Very Insightful Person

    I'm looking at the US is this on the high side?  I believe these should be around the low 40's ?
