3.0 Downstream channels
Channel Frequency (Hz) Power (dBmV) SNR (dB) Modulation Channel ID
1 267000000 2.6 42 QAM 256 17
2 139000000 3.2 41 QAM 256 1
3 147000000 3.1 41 QAM 256 2
4 155000000 3 41 QAM 256 3
5 163000000 2.9 41 QAM 256 4
6 171000000 2.7 41 QAM 256 5
7 179000000 2.6 41 QAM 256 6
8 187000000 2.5 41 QAM 256 7
9 195000000 2.8 41 QAM 256 8
10 203000000 2.7 41 QAM 256 9
11 211000000 3 41 QAM 256 10
12 219000000 2.9 41 QAM 256 11
13 227000000 2.7 41 QAM 256 12
14 235000000 2.6 41 QAM 256 13
15 243000000 2.4 41 QAM 256 14
16 251000000 2.3 41 QAM 256 15
17 259000000 2.4 42 QAM 256 16
18 275000000 2.5 42 QAM 256 18
19 283000000 2.5 42 QAM 256 19
20 291000000 2.7 42 QAM 256 20
21 299000000 2.6 42 QAM 256 21
22 307000000 2.6 41 QAM 256 22
23 315000000 2.4 41 QAM 256 23
24 323000000 2.3 41 QAM 256 24
25 331000000 2.2 41 QAM 256 25
26 339000000 2.2 41 QAM 256 26
27 347000000 2.2 42 QAM 256 27
28 355000000 2 42 QAM 256 28
29 363000000 2 42 QAM 256 29
30 371000000 1.8 42 QAM 256 30
31 379000000 1.5 41 QAM 256 31
32 387000000 1.4 41 QAM 256 32
3.0 Downstream channels
Channel Locked Status RxMER (dB) Pre RS Errors Post RS Errors
1 Locked 42 100 0
2 Locked 41 274 0
3 Locked 41 299 0
4 Locked 41 259 0
5 Locked 41 212 0
6 Locked 41 209 0
7 Locked 41 231 0
8 Locked 41 277 0
9 Locked 41 255 0
10 Locked 41 282 0
11 Locked 41 120 0
12 Locked 41 119 0
13 Locked 41 135 0
14 Locked 41 137 0
15 Locked 41 124 0
16 Locked 41 104 0
17 Locked 42 122 0
18 Locked 42 114 0
19 Locked 42 104 0
20 Locked 42 102 0
21 Locked 42 117 0
22 Locked 41 132 0
23 Locked 41 124 0
24 Locked 41 146 0
25 Locked 41 150 0
26 Locked 41 132 0
27 Locked 42 118 0
28 Locked 42 116 0
29 Locked 42 118 0
30 Locked 42 119 0
31 Locked 41 142 0
32 Locked 41 142 0
3.1 Downstream channels
Channel Channel Width (MHz) FFT Type Number of Active Subcarriers Modulation (Active Profile) First Active Subcarrier (Hz)
159 94 4K 1840 QAM 4096 1108
3.1 Downstream channels
Channel ID Locked Status RxMER Data (dB) PLC Power (dBmV) Corrected errors (Active
Profile) Uncorrectable errors (Active Profile)
159 Locked 43 4.3 931719419 0
3.0 Upstream channels
Channel Frequency (Hz) Power (dBmV) Symbol Rate (ksps) Modulation Channel ID
0 49600000 47.3 5120 QAM 64 1
1 43100000 46.8 5120 QAM 64 2
2 36600000 46.3 5120 QAM 64 3
3 30100000 46.3 5120 QAM 64 4
4 23600000 45.8 5120 QAM 64 5
3.0 Upstream channels
Channel Channel Type T1 Timeouts T2 Timeouts T3 Timeouts T4 Timeouts
0 ATDMA 0 0 1 0
1 ATDMA 0 0 1 0
2 ATDMA 0 0 1 0
3 ATDMA 0 0 0 0
4 ATDMA 0 0 0 0
3.1 Upstream channels
Channel Channel Width (MHz) Power (dBmV) FFT Type Modulation
6 10 41.2 2K QAM 256
3.1 Upstream channels
Channel Channel Type Number of Active Subcarriers First Active Subcarrier (Hz) T3 Timeouts T4 Timeouts
6
OFDMA 200 74000000 4 0
Network Log
Time Priority Description
[Mod - MACS removed]
e2:05:3b:95;CM-QOS=1.1;CM-VER=3.1;
